    3 Port 10/100M Unmanaged Gigabit Ethernet Converter Wall Mounting Installation

    3-port 10/100M unmanaged wall mounting Ethernet media converter

    Introduction

    MODEL1200 series are 3-port 100M media converter. It can convert Ethernet electrical signal into Ethernet optical signal to extend the transmission distance. It also has good isolation protection and data confidentiality. This series include three types of products with different mains input methods and provide 100M copper port, 100M fiber port. It adopts DIN-Rail or wall mounting to meet the requirements of different application scenes.


    This series of products conform to CE, FCC certification standards. Hardware adopts fanless, low power consumption, wide temperature and voltage design, which can suit for the scene environment with harsh requirements. It can be widely used in various fields.

    Specification

    Standard & Protocol

    IEEE 802.3 for 10Base-T

    IEEE 802.3u for 100Base-TX and 100Base-FX

    Copper Port

    10/100Base-T(X), RJ45, automatic flow control, full/half duplex mode, MDI/MDI-X autotunning

    Fiber Port

    Standard: 100Base-FX

    Connection mode: SC/ST/FC optional


    Transmission distance:

    Multimode: 2km

    Single mode: 20/40/60/80/100/120km


    Fiber cable:

    Multimode: 50/125μm or 62.5/125μm

    Single mode: 8.3/125μm, 8.7/125μm, 9/125μm or 10/125μm


    Transmission wavelength:

    Multimode: 1310nm

    Single mode: 1310nm or 1550nm

    LED Indicator

    Port indicator, power supply indicator

    Power Requirement

    Support three kinds of mains input methods

    External 5VDC, DC round head

    Built-in 220VAC, AC socket with switch

    Built-in 48VDC, 3-pin 5.08mm pitch terminal blocks

    Power Consumption

    4W

    Environmental Limit

    Operating temperature: -10~60℃

    Storage temperature: -20~70℃

    Relative humidity: 5%~95%(no condensation)

    Physical

    Characteristic

    Housing: metal

    Installation: wall or DIN-Rail mounting

    Dimension (W x H x D): 70.6mm×26mm×94mm (external power supply)

    115mm×30mm×173.2mm (built-in power supply)

    Certification

    CE, FCC, RoHS

    Warranty

    3 years


    Dimension
    Unit:mm


    Ordering Information


    Available Models100M Fiber Port100M Copper PortPower Supply Range
    MODEL1200-5VDC125VDC
    MODEL1200-220VAC12220VAC
    MODEL1200-48VDC1248VDC
