    24 Port Industrial Ethernet Switch -40~75 Centigrade Operating Temperature

    Ask Lasest Price
    Brand Name : 3onedata
    Model Number : IES1024
    Certification : CE, FCC, RoHS
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 3000 sets per month
    Delivery Time : 7 Working Days
    • Product Details
    • Company Profile

    24 Port Industrial Ethernet Switch -40~75 Centigrade Operating Temperature

    24-port 10/100M layer 2 unmanaged rack mounting industrial Ethernet switch

    Introduction

    IES1024 series are 24-port 100M layer 2 unmanaged industrial Ethernet switches. This series include eight types of products and provide full 100M copper ports, full 100M fiber ports, 100M copper/fiber ports. They adopt rack mounting to meet the requirements of different application scenes.


    The products conform to FCC, CE standard and adopt industrial grade 4 design. Hardware adopts fanless, low power consumption, wide temperature and voltage design and has passed rigorous industrial standard tests, which can suit for the industrial scene environment with harsh requirements for EMC. It can be widely used in smart grid, rail transit, smart city, safety city, new energy, aerospace, intelligent manufacturing, military project and other industrial fields.


    Specification

    Standard

    &

    Protocol

    IEEE 802.3 for 10Base-TX

    IEEE 802.3u for 100Base-TX and 100Base-FX

    Interface

    Copper port: 10/100Base-TX, RJ45, Automatic Flow Control, Full/half Duplex Mode, MDI/MDI-X Autotunning

    Fiber port: 100Base-FX

    LED Indicator

    Running Indicator, Port Indicator, Power Supply Indicator

    Switch

    Property

    Transmission mode: store and forward

    MAC address: 8K

    Packet buffer size: 3Mbit

    Backplane bandwidth: 12.8G

    Switch time delay: < 10μs

    Power

    Requirement

    100-240VAC/DC

    Environmental

    Limit

    Operating temperature range: -40~75℃

    Storage temperature range: -40~85℃

    Relative humidity: 5%~95%(no condensation)

    Physical

    Characteristic

    Housing: IP30 protection, metal

    Installation: 19 inches rack mounting

    Dimension (W x H x D): 441.6mm×44.6mm×207.9mm

    Industrial

    Standard

    IEC61000-4-2 (ESD),Level 4

    Air discharge: 15kV

    Contact discharge: 8kV

    IEC61000-4-4 (EFT), Level 4

    Power supply: ±4kV

    Ethernet interface: ±2kV

    Relay: ±4kV

    IEC61000-4-5 (Surge), Level 4

    Power supply: common mode ±4kV, differential mode ±2kV

    Ethernet interface: ±4kV

    Shock: IEC 60068-2-27

    Free fall: IEC 60068-2-32

    Vibration: IEC 60068-2-6

    Certification

    CE, FCC, RoHS

    Warranty

    5 years


    Dimension
    Unit:mm


    Ordering Information


    Available Models100M Fiber Port100M Copper PortPower Supply Range

    IES1024

    024

    100~240VAC/DC

    IES1024-2F222
    IES1024-4F420
    IES1024-8F816
    IES1024-12F1212
    IES1024-16F168
    IES1024-20F204
    IES1024-24F240
