    IP30 Waterproof USB To Serial Converter For Data Acquisition Control System

    USB to 4-port RS-232 converter

    Introduction

    USB4232 is a USB to RS-232 interface converter, which can achieve bilateral switching of data between USB interface and 4 RS-232 serial ports. The product supports 1 USB interface and 4 RS-232 serial ports. Serial port is equipped with 1500W surge protection and 15kV electrostatic protection, which can effectively protect the device from damage. It adopts desktop mounting to meet the requirements of different application fields.


    The product provides matched driver program software; USB interface connected to PC will make up a serial COM port in the computer system. PC host can communicate with RS-232 serial device via virtual COM port.


    Hardware adopts fanless, low power consumption, wide temperature design and has passed rigorous industrial standard tests, which can suit for the industrial scene environment with harsh requirements for EMC. It can be widely used in PLC, Industrial Automatic Control, IC Card Toll Collection System, and Data Acquisition Control System, etc.


    Specification

    Serial Port

    Standard: EIA RS-232C

    Quantity of serial port: 4 RS-232 serial ports

    RS-232 signal: RXD, TXD, DTR, GND, DSR, RST, CTS

    Baud rate: 300bps~115200bps

    Data bit: 7bit, 8bit

    Stop bit: 1bit, 2bit

    Parity bit: None, Even, Odd, Space, Mark

    Flow control: RTS/CTS, XON/XOFF

    Interface form: DB9, Male

    Transmission distance: 15m

    Interface protection: 1500W surge protection, 15kV electrostatic protection


    USB Port



    Standard: USB 1.1, USB 2.0

    Quantity of interfaces: 1 USB interface

    USB signal: VCC, DATA+, DATA-, GND

    Transmission rate: high speed 480Mbps, full speed 12Mbps

    Interface form: USB B-type socket, Female

    Transmission distance: 5m


    Operating System


    Windows 98/ME/2000/XP/Server 2003/Server 2008/7/Vista, Linux, MAC OS-X


    LED Indicator

    Power supply indicator, serial port data sending/receiving indicator


    Power Requirement

    Supports optional USB interface power supply or external 5VDC power supply, both can supply electricity simultaneously;Thereinto, 5VDC power supply adopts DC round head, external circle is negative pole, and inner core is positive pole

    Power Consumption

    300mA

    Environmental Limit

    Operating temperature: -20~60℃

    Storage temperature: -40~85℃

    Relative humidity: 5%~95% (no condensation)

    Physical

    Characteristic

    Housing: metal, IP30 protection grade

    Installation: desktop mounting

    Dimension (W x H x D): 160mm×28mm×94mm

    Weight: 500g

    Certification

    CE, FCC, RoHS

    Warranty

    3 years


    Dimension
    Unit:mm


    Ordering Information


    Available ModelsUSBRS-232Power Supply
    USB423214

    5VDC or USB power supply
