    Industrial 4G Router with Dual SIM, -40~75℃ operating temperature, 5 years warranty

    5-port 100M Ethernet + 2 serial ports + 2 SIM slots industrial 4G router

    Introduction

    IRT5300-AW-5T2D is industrial-grade 4G router. Its PoE power supply conforms to IEEE802.3af/at protocol standard. This product supports 5 100M copper ports (one of them supports PoE power receiving), 2 serial ports, 4 antenna interfaces and 2 SIM card slots, etc. It adopts DIN-Rail mounting, which can meet the requirements of different application scenes.
    Network management supports multiple software functions, like Cellular WAN, Ethernet WAN, ICMP Link Test, DHCP Setting, Dynamic Domain Name, Routing Table Setting, WLAN Setting, Port Forwarding, Port Redirection, DMZ Setting, Serial Port Application and Setting, UPnP Setting, VRRP, RIP, OSPF and Static DHCP, etc. It also supports firewall functions, such as IP Filtering, MAC Filtering, URL Filtering and Keyword Filtering, etc. and VPN tunneling functions like IPSec, PPTP, L2TP, etc. Network management could bring you great user experience though its friendly designed system interface and easy and convenient operation.
    The power supply input consists of two independent power supply circuits, which can ensure device’s normal operation when one fails. The design of DIP switch could implement device reboot and factory setting recovery. When power supply or port has link failure, ALARM indicator would be bright and send alerts for quick troubleshooting on the scene. Hardware adopts fanless, low power consumption, wide temperature and voltage design. It can be widely used in railway transportation, intelligent transportation, smart grid, environmental monitoring, fire monitoring, security monitoring, hydrological monitoring, public safety, industrial control, earthquake monitoring, meteorological monitoring, instrument monitoring and other industries.

    Features and Benefits

    • Support dual SIM card redundancy backup and Cellular network. It’s embedded with multiple 2G/3G/4G wireless communication modules
    • Support backup switch between PPPOE, DHCP, static IP and 4G networks to fit different scenes
    • Support network firewall, which can implement filtering and forwarding of IP, MAC, URL, keyword, etc.
    • DHCP, DHCP server could be used to distribute IP address with different policies
    • Support DDNS function, user can access server through domain names
    • Support VPN encryption protocols like GRE, PPTP, L2TP and IPSEC, which can ensure the privacy and integrity of data and prevent replay attack
    • Support multiple serial port operating modes like RealCom, TCP Server, TCP Client, UDP Server, UDP Client, etc.
    • Support NAT, which can implement conversion between public address and private address. Functions like port mapping and port redirection are also supported.
    • Log management records boot information, operation information and connection information
    • VRRP, RIP, OSPF could implement dynamic router configuration
    • Support timing reboot and ICMP link test reboot
    • Support hardware watchdog to ensure the reliability of system
    • Ping Test, Traceroute, Router Tracing could achieve network diagnosis and troubleshooting

    Specification

    Standard & Protocol

    IEEE802.11b/g/n for WLAN

    IEEE802.11i for wireless security

    IEEE802.11r for fast roaming

    IEEE802.3af/at for PoE

    IEEE 802.3 for 10BaseT

    IEEE 802.3u for 100BaseT(X)

    Security

    SSID Broadcast Switch, MAC Filtering, IP Filtering, URL Filtering, Keyword Filtering, WPA2-PASK and WEP SHARED Encryption, NAT, Port Mapping, Virtual Server, GRE, PPTP Client, PPTP Server, L2TP Client, L2TP Server and IPSEC VPN Encryption, DMZ

    Reliability

    Floating Route RIP, VRRP, Multi WAN Port and Wire/Wireless Interface Backup, Link Online Test, Embedded Watchdog

    Troubleshooting

    Ping, Traceroute, Port Loopback

    WIFI Transmission Rate

    802.11n: 6.5~300Mbps

    802.11b: 11/5.5/2/1Mbps

    802.11g: 54/48/36/24/18/12/9/6Mbps

    WIFI RF

    Channel: 2.412GHz~2.4835GHz

    RF power output: 23dBm

    Modulation scheme: DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM


    WIFI Receiving Sensitivity

    802.11n_HT40: -82dBm@MCS0, -64dBm@MCS7

    802.11n_HT20: -85dBm@MCS0, -67dBm@MCS7

    802.11g: -91dBm@6Mbps, -72dBm@54Mbps

    802.11b: -93dBm@1Mbps, -87dBm@11Mbps


    WIFI Transmission Power

    802.11n_HT40: 23dBm@MCS0, 20dBm@MCS7

    802.11n_HT20: 23dBm@MCS0, 20dBm@MCS7

    802.11g: 23dBm@6Mbps, 20dBm@54Mbps

    802.11b: 23dBm@1Mbps, 23dBm@11Mbps

    LTE Operating Frequency Band

    TDD-LTE: Band38/39/40/41

    FDD-LTE: Band 1/3/5/7/8/20

    WCDMA: Band1/5/8

    TD-SCDMA: B34/39

    EVDO/CDMA1X: BC0

    GSM: Band 3/8

    LTE Bandwidth

    TDD-LTE: Rel 9 Cat4 TDD-LTE 112Mbps/30Mbps

    FDD-LTE: Rel 9 Cat4 FDD-LTE 150Mbps/50Mbps

    DC-HSPA+: 42Mbps/5.76Mbps

    HSPA+: 21Mbps/5.76Mbps

    UMTS: 384kbps/384kbps

    EVDO RevA: 3.1Mbps/1.8Mbps

    EVDO Rev0: 2.4Mbps/153.6kbps

    TD-HSPA: 4.2Mbps/2.2Mbps

    TD- SCDMA: 2.8Mbps/2.2Mbps

    CDMA 1x: 153.6kbps/153.6kbps

    EDGE: 236.8kbps/236.8kbps

    GPRS: 85.6kbps/85.6kbps

    LTE Sensitivity

    GSM: <-108dBm

    WCDMA: <-109dBm

    TD-SCDMA: <-108dBm

    TDD-LTE:

    Band38/39/40: <-100dBm@5MHz BW

    Band41: <-98dBm@5MHz BW

    FDD-LTE:

    Band1: <-100dBm@5MHzBW

    Band3/8: <-97dBm@5MHzBW

    Band5: <-98dBm@5MHzBW

    CDMA: <-108dBm

    EVDO: <-108dBm

    Maximum Transmission Power Of LTE

    LTE-FDD/TDD: 23 ±2dBm

    WCDMA: 24 +1/-3dBm

    TD-SCDMA: 24 +1/-3dBm

    EVDO/CDMA 1X: 24 ±1dBm

    GSM850/900: 33±2dBm

    GSM1800/1900: 30±2dBm


    Interface

    Copper port: 5 10/100Base-T(X) RJ45 ports, which could be configured to 5 LAN or 4 LAN+1 WAN

    Serial port: 2 RS-232 or 2 RS-485

    I/O port: reserved

    SIM slot: 2 SIM slots, redundancy backup, support 1.8V/3V SIM card

    Antenna interface:

    2 LTE antenna interfaces, SMA female. Master antenna is used for sending/receiving information; slave antenna is used for receiving information

    2 WIFI antenna interfaces, SMA female


    Serial Port Parameter

    ESD protection: ±15KV

    Data bit: support 7, 8bits. 8 bits by default.

    Check bit: support No Check, Odd Check, Even check

    Stop bit: 1, 2 bit

    Baud rate: 300bps-15200bps

    RS-232: TXD, RXD, GND

    RS-485: Data+(A), Data-(B), GND


    LED Indicator

    WLAN indicator, LTE signal strength indicator, running indicator, alarm indicator, power supply indicator, SIM indicator, LTE indicator, PoE indicator, copper port connection indicator, serial port connection indicator, RLY indicator, DI indicator

    Power Requirement

    Dual power supply redundancy, voltage range: 12~48VDC, support non-polarity, reverse polarity protection, built-in overcurrent 2.0 protection

    support standard 48V PoE power supply, which conforms to 802.3af/802.3at standard(100m max)

    Power Consumption


    No-load: 3.38W@24VDC

    Full-load: 7.15W@24VDC


    Environmental Limit

    Operating temperature: -40~75℃

    Storage temperature: -40~85℃

    Relative humidity: 5%~95%(no condensation)

    Physical

    Characteristic

    Housing: IP30 protection, metal
    Dimension (W x H x D): 53mm x 138mm x 110 mm(exclude antenna)
    Installation: DIN-Rail mounting
    Weight:570g

    Industrial Standard

    IEC 61000-4-2 (ESD, electrostatic discharge), Level 3

    Air discharge: ±8kV

    Contact discharge: ±6kV


    IEC 61000-4-4 (EFT, electrical fast transient), Level 3

    Power supply: ±2kV

    Ethernet port: ±1kV

    Relay: ±2kV


    IEC 61000-4-5 (Surge), Level 3

    Power supply: common mode±2kV, differential mode±1kV

    Ethernet port: ±2kV

    Relay: common mode±2kV, differential mode±1kV


    Shock: IEC 60068-2-27

    Free fall: IEC 60068-2-32

    Vibration: IEC 60068-2-6


    Certification

    CE, FCC, RoHS

    Warranty

    5 years


    Dimension

    Unit:mm

    Ordering Information


    Available Models100m Copper PortSerial PortAntennaSIM SlotPower Supply
    IRT5300-AW-5T2D-2P12_485242

    12~48VDC or 48VDC PoE
