    IP40 Waterproof 6 Port Industrial Ethernet Switch 4.8Gbps Switch Capacity

    Ask Lasest Price
    Brand Name : 3onedata
    Model Number : IES206
    Certification : CE, FCC, RoHS
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 3000 sets per month
    Delivery Time : 7 Working Days
    • Product Details
    • Company Profile

    IP40 Waterproof 6 Port Industrial Ethernet Switch 4.8Gbps Switch Capacity

    6-port 100/1000M layer 2 unmanaged DIN-rail mounting industrial Ethernet switch

    Introduction

    IES206 series are 6-port 100M/gigabit unmanaged industrial Ethernet switches. The series provide 100M copper ports, gigabit fiber ports and SFP slots. They also adopt DIN-Rail mounting or wall mounting, which can meet the requirements of different application scenes.


    The input power supply is two independent power supply circuits which can ensure the normal operation of the device when one power supply fails. Hardware adopts fanless, low power consumption, wide temperature and voltage design and has passed rigorous industrial standard tests, which can suit for the industrial scene environment with harsh requirements for EMC. It can be widely used in smart grid, railway transportation, smart city, safe city, new energy, aerospace, intelligent manufacturing, military project and other industrial fields.

    Specification

    Standard

    &

    Protocol

    IEEE 802.3 for 10Base-T

    IEEE 802.3u for 100Base-TX

    IEEE 802.3z for 1000Base-X

    Interface

    Copper port: 10/100Base-T(X), RJ45, Automatic Flow Control, Full/Half Duplex Mode, MDI/MDI-X Autotunning

    Fiber port: 1000Base-FX, SC/ST/FC optional

    SFP slot: 1000Base-SFP

    LED Indicator

    Running Indicator, Port Indicator, Power Supply Indicator

    Switch

    Property

    Transmission mode: store and forward

    MAC address: 8K

    Packet buffer size: 1Mbit

    Backplane bandwidth: 7.6G

    Switch time delay: <10μs

    Power

    Requirement

    12~48VDC, 4-pin 7.62mm pitch terminal blocks

    dual power supply redundancy, non-polarity, reverse connection protection

    Environmental

    Limit

    Operating temperature range: -40~75℃

    Storage temperature range: -40~85℃

    Relative humidity: 5%~95%(no condensation)

    Physical

    Characteristic

    Housing: IP40 protection, metal

    Installation: DIN-Rail mounting or wall mounting

    Dimension (W x H x D):

    53mm×136mm×105mm(IES206-2GS)

    53mm×138mm×110mm(IES206-2GF)

    Industrial

    Standard

    IEC 61000-4-2 (ESD), Level 4

    Air discharge: ±15kV

    Contact discharge: ±8kV


    IEC 61000-4-4 (EFT), Level 4

    Power supply: ±4kV

    Ethernet port: ±2kV

    Relay: ±4kV


    IEC 61000-4-5 (Surge), Level 4

    Power supply: common mode ±4kV, differential mode±2kV

    Ethernet port: ±2kV

    Relay: common mode±4kV, differential mode±2kV


    Shock: IEC 60068-2-27

    Free fall: IEC 60068-2-32

    Vibration: IEC 60068-2-6

    Certification

    CE, FCC, RoHS

    Warranty

    5 years


    Dimension
    Unit:mm



    Ordering Information


    Available ModelsGigabit SFP SlotGigabit Fiber Port100M Copper PortPower Supply Range
    IES206-2GS204

    12~48VDC

    dual power supply

    IES206-2GF024
