    24Gbps Industrial Ethernet Switch 12 Port DIN Rail Mounting Installation

    12-port full gigabit unmanaged DIN-rail mounting industrial Ethernet switch

    Introduction

    IES3012G series are 8/12-port full Gigabit layer 2 unmanaged industrial Ethernet switches. This series of products provide Gigabit copper port and SFP slot. They adopt DIN-Rail mounting to meet the requirements of different application scenes.


    Power supply input is two independent power supply circuits, which can ensure the device normal operation when one of the power supplies breaks down. Design of DIP switch can achieve power supply alarm function. When power supply occurs link failure, ALARM indicator will be bright and send out alarm, meanwhile, alarm device connected to the relay will send out alarm for rapid scene troubleshooting. Hardware adopts fanless, low power consumption, wide temperature and voltage design and has passed rigorous industrial standard tests, which can suit for the industrial scene environment with harsh requirements for EMC. It can be widely used in smart grid, rail transit, smart city, safety city, new energy, aerospace, intelligent manufacturing, military project and other industrial fields.


    Specification

    Standard

    &

    Protocol

    IEEE 802.3 for 10Base-T

    IEEE 802.3u for 100Base-TX

    IEEE 802.3ab for 1000Base-T

    IEEE 802.3z for 1000Base-X

    Interface

    Copper port: 10/100/1000Base-T(X), RJ45, Automatic Flow Control, Full/half Duplex Mode, MDI/MDI-X Autotunning

    SFP slot: 1000Base-SFP

    Alarm port: 2-pin 7.62mm pitch terminal blocks, support 1 relay alarm output, current carrying capacity 5A@30VDC or 2A@250VAC

    LED Indicator

    Running Indicator, Port Indicator, Power Supply Indicator, Alarm Indicator

    Switch

    Property

    Transmission mode: store and forward

    MAC address: 8K

    Packet buffer size: 4Mbit

    Backplane bandwidth: 24G

    Switch time delay: <10μs

    Power

    Requirement

    12~48VDC, 4-pin 7.62mm pitch terminal blocks

    dual power supply redundancy, reverse polarity protection, nonpolarity

    Environmental

    Limit

    Operating temperature range: -40~75℃

    Storage temperature range: -40~75℃

    Relative humidity: 5%~95%(no condensation)

    Physical

    Characteristic

    Housing: IP40 protection, metal

    Installation: DIN-Rail mounting

    Weight: ≤0.96kg

    Dimension (W x H x D): 70mm×160mm×130mm

    Industrial

    Standard

    IEC 61000-4-2 (ESD), Level 4

    IEC 61000-4-4 (EFT), Level 4

    IEC 61000-4-5 (Surge), Level 4

    Shock: IEC 60068-2-27

    Free fall: IEC 60068-2-32

    Vibration: IEC 60068-2-6

    Certification

    CE, FCC, RoHS

    Warranty

    5 years


    Dimension
    Unit:mm


    Ordering Information


    Available ModelsGigabit SFP SlotGigabit Copper PortPower Supply Range
    IES3012G-4GS48

    12~48VDC

    dual power supply

    IES3012G-8GT08
